What's New
- Provides a high performance Dual Radio 802.11ax AP with 4 spatial streams (4X4) for higher capacity and coverage.
- This series features maximum data rates of 4.8Gbps in the 5GHz band and 574 Mbps in the 2.4GHz band (for an aggregate peak data rate of 5.3Gbps).
- Includes 2.5G Ethernet uplink port and 160 MHz channel bandwidth for increased wireless throughput.
- Wi-Fi 6 certification supports all mandatory 802.11ax features that include MU-MIMO, OFDMA, TWT, and more.
- Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access.
- Aruba Instant On mobile app and/or cloud-based web portal allows for easy network management onsite or remotely.
Technical Specifications:
Certifications EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Input voltage Power over Ethernet (POE): 802.3at (class 4)
Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC) DC power (12V)
Note: Power sources are sold separately unless you purchase the bundle SKU
Wi-Fi antenna Down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
Connectivity, standard Ultra-fast 802.11ax, 4x4:4
Ports Uplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot
Mounting The access point ships with a white mount clip that can attach to both walls and ceilings.
Mounts that match the design of the APs can be purchased separately
Power consumption Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC)
Radio coverage Dual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
Detailed product description Includes 12V Power Adapter with Localized Power Plug
Weight 1.18 kg (2.6 lb)
Dimensions 5.1 x 20.3 cm (2 x 8 x 8 in)
