10 Gbps Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage.
- Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
- Includes full UniFi application suite for device management
- 5 Gbps routing with IDS/IPS
- (1) 10G SFP+*, (8) GbE RJ45 LAN ports
- (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
- (2) 3.5" NVR HDD bays with RAID data protection
- Built-in 128 GB SSD for NVR detection recordings
- 1.3" touchscreen
Technical Specifications
MechanicalDimensions442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2")Weight4.7 kg (10.4 lb)Enclosure materialAluminium CNC, SGCC steelMount materialSGCC steelHardwareProcessorQuad-core ARM® Cortex®-A57 at 2.0 GHzSystem memory8 GB DDR4On-board storage32 GB eMMC
Integrated 128 GB SSDManagement interfaceEthernet
BluetoothNetworking interfaceLAN:
(8) GbE RJ45 ports
(1) 10G SFP+ port
WAN:
(1) 2.5 GbE RJ45 port
(1) 10G SFP+ portIDS/IPS throughput5 Gbps*
*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.Power method(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz
(1) USP-RPS DC input, 11.5V DC, 8.7APower supplyAC/DC, internal, 100WSupported voltage range100—240V ACMax. power consumption100WESD/EMP protectionAir: ± 15kV, contact: ± 8kVLCM display(1) 1.3" touchscreenButtonFactory resetAmbient operating temperature-10° to 40° C (14° to 104° F)Ambient operating humidity5 to 95% noncondensingCertificationsCE, FCC, ICGateway FeaturesPerformanceRedundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reportingNext-generation securityApplication-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewallAdvanced networkingLicense-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP supportLEDsEthernetGreen: link/activitySFP+Green: link/activityHDDWhite: disk activity
Amber: disk errorRPSBlue: ready
