Incredibly compact, indoor/outdoor AP with versatile mounting options and long-range external antenna support.
Technical Specifications
Dimensions
137 x 84 x 34 mm
(5.4 x 3.3 x 1.3")
WiFi Standard
WiFi 5
Spatial Streams
4
Coverage Area
115 m² (1,250 ft²)
Max. Client Count
200+
Uplink
GbE
Mounting
Ceiling, Wall, Pole, Table (With Accessory)
(Mounts Included)
Desktop Stand (Optional)
Weatherproofing
IPX6
Power Method
PoE
Performance
MIMO
5 GHz
2 x 2 (DL MU-MIMO)
2.4 GHz
2 x 2 (DL MU-MIMO)
Max. Data Rate
5 GHz
866.7 Mbps (BW80)
2.4 GHz
300 Mbps (BW40)
Antenna Gain
5 GHz
6.1 dBi
2.4 GHz
4.7 dBi
Max. TX Power
5 GHz
20 dBm
2.4 GHz
20 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ac (WiFi 5)
6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
Features
Wireless Meshing
✓
Band Steering
✓
802.11v BSS Transition Management
✓
802.11r Fast Roaming
✓
802.11k Radio Resource Management (RRM)
✓
Advanced Radio Management
✓
Passpoint (Hotspot 2.0)
✓
Captive Hotspot Portal
Custom Branding Landing Page
✓
Voucher Authentication
✓
Payment-Based Authentication
✓
External Portal Server Support
✓
Password Authentication
✓
Guest Network Isolation
✓
Private Pre-Shared Key (PPSK)
✓
WiFi Speed Limiting
✓
Client Device Isolation
✓
WiFi Schedules
✓
RADIUS over TLS (RadSec)
✓
Dynamic RADIUS-assigned VLAN
✓
Hardware
Max. Power Consumption
8W
Supported Voltage Range
44–57V DC
Networking Interface
(1) GbE RJ45 port
Weight
173 g (6.1 oz)
Wind Loading
33.2 N at 200 km/h (7.5 lbf at 125 mph)
Pole Mount Diameter
1~2" (25–50 mm)
Antennas
(1) Internal antenna
(2) RP-SMA connectors
Management
Ethernet
Enclosure Material
UV-stabilized polycarbonate
Mount Material
Polycarbonate, SGCC steel, plastic
LEDs
System
(1) Power: White/Blue
(4) Mesh Signal: Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80
NDAA Compliant
✓
Certifications
CE, FCC, IC, Anatel: 06237-24-08356
Operating Frequency
US/CA:
2400 - 2472 MHz
U-NII-1: 5150 - 5250 MHz
U-NII-2A: 5250 - 5350 MHz
U-NII-2C: 5470 - 5725 MHz
U-NII-3: 5725 - 5850 MHz
Worldwide:
2400 - 2483.5 MHz
5150 - 5850 MHz
Ambient Operating Temperature
-40 to 60° C (-40 to 140° F)
Ambient Operating Humidity
5 to 95% noncondensing
Software
Application Requirements
UniFi Network
Version 7.5.187 and later
Warranty
7-Day Replacement Warranty
The unit is eligible for a one-time, same-item replacement within seven (7) days from the date of receipt or delivery, subject to the following conditions:
✓ The item must be in its original, unused condition.
✓ All original packaging and accessories must be included.
✓ A valid proof of purchase (receipt) is required.
Note: Physical damage or customer-induced damage is not covered.
